316L 321 Stainless Steel Well Pipe Filter Mesh Slotted 10 Inch 10ft Length

Product Categories
Anping County Xinlu Wire Mesh Products Co., Ltd.
Contact Now

316L 321 Stainless Steel Well Pipe Filter Mesh Slotted 10 Inch 10ft Length

Brand Name : Anping County Xinlu Wire Mesh Products Co.,Ltd

Model Number : XL- stainless steel filter screen -08

Place of Origin : Anping County, Hebei Province, China

MOQ : 4pcs

Price : Negotiable according to the specification

Payment Terms : T/T

Supply Ability : 100pcs/20days

Delivery Time : 8-10days

Packaging Details : wood case

Name : 10 Inch X L 10ft Stainless Steel Water Well Slotted Johnson Filter Pipe

Material : SS304, or 316L, 321, Duplex stainless steel, Hastelloy

v wire : 3x4.6mm

OD : 273mm, or customized

Connection Type : welded ring, threaded API, PT, NPT，BST, flange, etc

Slot : 0.040"

Advantage : Easy for installation, Long using life, Anti-corrosion

Application : Filter, filter, mineral, gas/oil/liquid filtration, Industry

Contact Now

10 Inch X L 10ft Stainless Steel Water Well Slotted Johnson Filter Pipe by Anping County Xinlu Wire Mesh Products Co., Ltd.

[Anping County Xinlu Wire Mesh Products Co., Ltd.] introduces our 10 Inch X L 10ft Stainless Steel Water Well Slotted Johnson Filter Pipe, designed for superior performance in water well filtration applications.

Key Features:

  • Precision Slot Control: Ensures consistent flow rates and high filtration accuracy.
  • Robust Construction: Offers integrity at every welding point, ensuring a strong and reliable screen.
  • Customizable Options: Weld rings or threaded fittings based on customer requirements.
  • Multiple Wire Profiles: Available to suit various applications and specifications.

Our Johnson Wire screen pipes are ideal for a range of applications, including gravel pack, stand-alone screen applications, and geological formations with small, fine particles. They are also perfect for water wells where gravel packs will be installed, thin aquifers requiring maximum open area, and both large- and small-diameter deep wells.

Technical Specifications:

  • Materials: Premium stainless steel for corrosion resistance and durability.
  • Applications: Water wells, water supply systems, refining & petrochemical, filter equipment, drum filters, and sand control.

Stainless Steel Water well steel slotted Johnson screen pipe Specifications:

sizes
(inch)		 OD
(mm)		 slot
(mm)		 Length
(m)		 Tenslile
strength		 collapse
Strength

wrap wire
vee-shaped wire

(Width x height:mm)

 support rod
Round wire (mm)
3-1/2 88.9 1 2.9 >22 10.2 2.3 x 3.5 3.0MMx22
4-1/2 114.3 1 2.9 >28 11.5 2.3 x 3.5 3.0MM×22
6-5/8 168.3 0.75 5.8 >40 12.8 2.3 x 3.5 3.8MM×32
6-5/8 168.3 1 5.8 >33 12.8 2.3 x 3.5 3.8MM×32
6-5/8 168.3 0.63 5.8 >83 45 3.0 x 6.0 5.OMM×32
8-5/8 219.1 1 5.8 >34 21.9 2.3 x 3.5 3.8MMx48
8-5/8 219.1 1 5.8 >50 38.2 3.0 x 4.6 4.0MMx48
8-5/8 219.1 1 5.8 >60 46 3.05 x 6.35 5.0MMx48
10-3/4 273.1 0.75 5.8 >50 9 2.5 x 4 .0 3.8MM×55
10-3/4 273.1 1 5.8 >60 39.5 3.0 x 4.6 4.5MMx55
10-3/4 273.1 1 5.8 >100 48 3.2 x 6.0 5.0MM×55
12-3/4 323.9 1 5.8 >120 37.2 3.0 x 6.0 4.0MMx56
14 355.6 1 2.9 >80 37.8 3.0 x 5.0 4.0MMx59
16 426 1 2.9 >80 37.5 3.0 x 5.0 4.OMM×64

　PROFILE WIRE
　WIDTH(mm) 1.00 1.50 1.50 2.00 2.30 2.50 3.00 3.05
　HEIGHT(mm) 2.00 2.00 2.50 3.80 3.50 4.00 4.60 6.35

　SUPPORT ROD 316L 321 Stainless Steel Well Pipe Filter Mesh Slotted 10 Inch 10ft Length
ROUND
　WIDTH(mm) 1.80 2.00 2.50 3.00 3.00 Ø2.5--Ø6mm
　HEIGHT(mm) 2.50 3.00 4.00 4.60 6.00 ----

Package of Screen Pipes:


Plastic bubble bag packaging
Transparent plastic bag inside, woven bag outside
Wooden box
Pallet

FAQ:

  • Sample Orders: Welcome for quality testing; mixed samples accepted.
  • Lead Time: 3-5 days for sample preparation, 15-25 working days for mass production.
  • MOQ: Low MOQ, starting from 3 pieces for sample checking.
  • Shipping: Options include airline, sea, rail, or express courier services (EMS, DHL, UPS, FedEx, TNT) with 5-7 days arrival.
  • Order Process: Specification confirmation, quotation, order placement with deposit, and production arrangement.
  • Logo Printing: Custom logo printing available upon request.

[Anping County Xinlu Wire Mesh Products Co., Ltd.] - Your partner for high-quality stainless steel water well filter pipes.
